Walzstahl
Grobbleche................................................................................................. 124 Tôles moyennes et fortes / Medium and heavy plates Riffelbleche. ............................................................................................... 125 Tôles striées / Checker plates Tränenbleche........................................................................................... 125 Tôles larmées / Bulb plates Verschleißbleche / Kesselbleche.......................... 126 Tôles d’usure/Tôles chaudières / Wear plates/Boiler plates Gebeizte Bleche................................................................................. 127 Tôles décapées / Pickled plates Gebeizte Feinkornbaustahl-Bleche. ................. 127 Tôles à grain fin décapées / Fine grained construction steel Feinbleche.................................................................................................... 128 Tôles fines / Sheets Verzinkte Bleche................................................................................ 129 Tôles galvanisées / Galvanized sheets Lochbleche................................................................................................. 130 Tôles perforées / Perforated sheets INHALT Walzstahl Acier laminé Rolled Steel Walzstahl
Rundstahl...................................................................................................... 131 Ronds / Rounds Vierkantstahl............................................................................................ 131 Carrés / Squares Bandstahl in Stäben.................................................................... 132 Feuillards en barres / Strip materials in bars Flachstahl...................................................................................................... 133 Plats / Flats Breitflachstahl. ...................................................................................... 134 Larges plats / Universal plates Winkelstahl. ................................................................................................ 135 Cornières / Angles T-Stahl................................................................................................................. 139 Profils en T / T-section steel INHALT Walzstahl Acier laminé Rolled Steel Walzstahl
U-Stahl. .............................................................................................................. 139 Profils en U / Channel sections steel Verzinkter Stabstahl.................................................................... 140 Laminés marchands galvanisés / Galvanized merchant bars Formstahl. ..................................................................................................... 143 Profils / Sections Breitflanschträger........................................................................... 146 Poutrelles à larges ailes / Wide-flanged beams Schnittbilder. ............................................................................................ 149 Coupes transversales / Cross sections Gewichtstabelle.................................................................................. 150 Tableau des poids / Table of weights Spezialprofile........................................................................................... 152 Profils speciaux / Special profiles Technische Daten............................................................................ 165 Données techniques / Technical data S Walzstahl INHALT Acier laminé Rolled Steel Walzstahl
INHALT Walzstahl Matériel de construction Construction Material Gitterroste.................................................................................................... 168 Grilles normalisées / Standard Grills Garagenroste.......................................................................................... 168 Grilles pour revêtement de remises / Garage paving grills Treppenstufen........................................................................................ 168 Grilles pour marches d’escalier / Doorstep grills Draht/Drahterzeugnisse....................................................... 169 Fil étiré/tréfilés / Drawn wire / wire products bauzubehör
Walzstahl 124 P Lagervorrat p kurzfristig lieferbar S 235 JR (R St 37.2) EN 10025-2 Grobbleche Tôles moyennes et fortes / Medium and heavy plates Grobbleche sind in den oben genannten Güten auch in anderen, individuell benötigten Fixmaßen lieferbar. Wildmaß-Grobbleche S 235 JR und S 355 JR Brennzuschnitte bis 300 mm Coils und Fixformate im Bandbereich Fragen Sie bei uns an! Format kg/Tafel 1000 x 2000 kg/Tafel 1250 x 2500 kg/Tafel 1500 x 3000 3 48 P 75 P 108 P 4 64 P 100 P 144 P 5 80 P 125 P 180 P 6 96 P 150 P 216 P 8 128 P 200 P 288 P 10 160 P 250 P 360 P 12 192 P 300 P 432 P 15 240 P 375 P 540 P 20 320 P 500 P 720 P 25 400 P 625 p 900 p 30 480 P 750 p 1080 p 40 640 P 1000 p 1440 p Dicken bis 300 mm lieferbar Dicke mm
Walzstahl 125 P Lagervorrat p kurzfristig lieferbar S 235 JR (R St 37.2) EN 10025-2 (DIN 59220) S 235 JR (R St 37.2) EN 10025-2 (DIN 59220) Riffelbleche Tôles striées / Checker plates Tränenbleche Tôles larmées / Bulb plates Dicke mm kg/Tafel 1000 x 2000 4/ 6 76 p 5/ 7 92 p 6/ 8 108 p 8/10 140 p 10/12 172 p 12/14 204 p 15/17 252 p Dicke mm kg/Tafel 1000 x 2000 kg/Tafel 1250 x 2500 kg/Tafel 1500 x 3000 3/ 5 50 P 79 P 113 P 4/ 6 68 P 107 P 153 P 5/ 7 84 P 132 P 189 P 6/ 8 102 P 160 P 230 P 8/10 134 P 210 P 302 P 10/12 166 P 260 P 374 P 12/14 198 p 15/17 246 p
Walzstahl 126 P Lagervorrat p kurzfristig lieferbar HB 400 / 450 / 500 / 600 verschiedener Werke sowie die Güten 1.2080 / X210Cr12 (W12) 1.3401 / X120Mn12 Warmgewalzte Erzeugnisse aus Baustählen S690QL 1.8928 S960QL 1.8933 Vergütungsstähle nach DIN EN 10083-1/-2 C 45 1.1191 42 CrMo4 1.7225 Legierte Einsatzstähle nach DIN EN 10081 16MnCr5 1.7131 20MnCr5 1.7147 Druckbehälterstähle nach DIN EN 10028-2 und DIN EN 10028-3 P265GH 1.0425 Unlegierte Baustähle nach DIN EN 10025-2 S235JR 1.0038 S275JR 1.0044 S355JR 1.0045 Lieferzustände, Formate und Stärken sowie nicht augeführte Güten auf Anfrage. Brennteile und Formteile nach Produktionsreifer Zeichnung oder neutraler DXF Datei. Verschleißbleche
Walzstahl 127 P Lagervorrat p kurzfristig lieferbar S 235 JR (R St 37.2) EN 10025 (1541) Gebeizte Bleche Tôles décapées / Pickled plates Dicke mm kg/Tafel 1000 x 2000 kg/Tafel 1250 x 2500 kg/Tafel 1500 x 3000 4 64 P 100 P 144 P 5 80 P 125 P 180 P 6 96 P 150 P 216 P 8 128 P 200 P 288 P 10 160 P 250 P S 355 MC EN 10149 Gebeizte Feinkornbaustahl-Bleche Tôles à grain fin décapées / Fine grained construction steel Dicke mm kg/Tafel 1000 x 2000 kg/Tafel 1250 x 2500 kg/Tafel 1500 x 3000 3 48 P 75 P 108 P 4 64 P 100 P 144 P 5 80 P 125 P 180 P 6 96 P 150 P 216 P 8 128 P 200 P 288 P 10 160 P 360 P
Walzstahl 128 P Lagervorrat p kurzfristig lieferbar DC 01 (St1203) EN 10130 (1623) Feinbleche Tôles fines / Sheets DC 04 (St1403) EN 10130 (1623) Feinbleche Tôles fines / Sheets Dicke mm kg/Tafel 1000 x 2000 kg/Tafel 1250 x 2500 0,5 8 P 0,63 10 P 0,75 12 P 0,88 14 P 1 16 P 25 P 1,5 24 P 37,5 P 1,75 28 P 2 32 P 2,5 40 P 2,99 48 P Dicke mm kg/Tafel 1000 x 2000 kg/Tafel 1250 x 2500 kg/Tafel 1500 x 3000 0,5 8 P 0,63 10 P 0,75 12 P P 0,88 14 P 1 16 P 25 P 36 P 1,25 20 P 31,25 P 45 p 1,5 24 P 37,5 P 54 P 2 32 P 50 P 72 P 2,5 40 P 62,5 P 90 P 2,99 48 P 75 P 108 P
Walzstahl 129 P Lagervorrat p kurzfristig lieferbar DX 51 D + Z (St 02 Z) EN 10142 (59232) Feuerverzinkte Bleche Tôles galvanisées à chaud / Hot-galvanized sheets DC 01 + ZE (St 12 ZE) EN 10152 Elektrolytisch verzinkt Tôles galvanisées par électrolyse / Dip-galvanized sheets Dicke mm kg/Tafel 1000 x 2000 kg/Tafel 1250 x 2500 kg/Tafel 1500 x 3000 0,63 10 P 0,75 12 P 19 P 0,88 14 P 22 P 1,00 16 P 25 P 36 P 1,25 20 P 31,25 P 1,50 30 P 37,5 P 54 P 2,00 32 P 50 P 72 P 2,50 40 P 62,5 P 90 P 2,99 48 P 75 P 108 P 4,00 64 P 100 P 144 P 5,00 80 P 125 P 180 P Dicke mm kg/Tafel 1000 x 2000 kg/Tafel 1250 x 2500 kg/Tafel 1500 x 3000 0,5 8 P 0,63 10 P 15,6 P 0,75 12 P 0,88 14,4 P 22 P 1 16 P 25 P 1,25 20 P 31,25 P 45 P 1,5 24 P 37,5 P 54 P 2 32 P 50 P 72 P 2,5 40 P 62,5 P 90 P 2,99 48 P 75 P 108 P
Walzstahl 130 P Lagervorrat p kurzfristig lieferbar Lochbleche Tôles perforées / Perforated sheets DC 01 / DD 11 EN 10130 (DIN 24041) + EN 10111 Quadratlochung geradreihig (Qg), blank w - t Stärke 1000/2000 1250/2500 1500/3000 Qg 5-8 1 P Qg 5-8 1,5 P Qg 8-10 1,5 P Qg 8-12 1 P Qg 8-12 1,5 P Qg 8-12 2 P Qg 10-15 1 P Qg 10-15 1,5 P P P Qg 10-15 2 P Quadratlochung Lochweite w + Stegbreite c = Teilung t Rundlochung Rundlochung versetzt (Rv), blank w - t Stärke 100/200 1250/2500 Rv 3-5 1,5 P Rv 5-8 1 P Rv 5-8 1,5 P Rv 5-8 2 P Rv 10-15 1 P Rv 10-15 1,5 P P Rv 10-15 2 P Rv 10-15 3 P Andere Abmessungen auf Anfrage. Verzinkte Lochbleche w - t Stärke 1000/2000 1250/2500 Qg 10-15 1,5 P P Rv 5-8 1 P Rv 5-8 1,5 P Rv 10-15 1,5 P P Rv 10-15 2 P P
Walzstahl 131 P Lagervorrat p kurzfristig lieferbar S 235 JR EN 10025 Länge: 6 m Rund bis 40 mm Vorrat. Rest kurzfristig lieferbar bzw. sofort in Güte S 355! mit WZ 2.2 oder 3.1 und CE-Zeichen Profilstahl sägen wir auf Wunsch auf Ihr Fixmaß. Reststücke müssen bis Ø 60 mm übernommen werden. Rund- und Vierkantstahl Ronds et carrés / Rounds and squares mm kg/m rund kg/m vierkant 6 0,222 P 0,283 P 8 0,395 P 0,502 P 10 0,617 P 0,785 P 12 0,888 P 1,13 P 14 1,21 P 1,54 P 15 1,39 P 1,77 P 16 1,58 P 2,01 P 18 2,00 P 2,54 P 20 2,47 P 3,14 P 22 2,98 P 3,80 P 24 3,55 P 4,52 p 25 3,85 P 4,91 P 26 4,17 p 5,31 p 28 4,83 P 6,15 p 30 5,55 P 7,07 P 32 6,31 p 8,04 p 35 7,55 P 9,60 P 36 7,99 p mm kg/m rund kg/m vierkant 38 8,9 p 40 9,86 P 12,6 P 42 10,9 p 45 12,5 p 15,9 P 48 14,2 p 50 15,4 p 19,6 P 55 18,7 p 23,7 p 60 22,2 p 28,3 P 65 26,0 p 33,2 p 70 30,2 p 38,5 P 75 34,7 p 80 39,5 p 50,2 P 85 44,5 p 90 49,9 p 63,6 P 100 78,5 P
Walzstahl 132 P Lagervorrat p kurzfristig lieferbar S 235 JR EN 10025 Bandstahl in Stäben Feuillards en barres / Strip materials in bars Gewichte siehe Gewichtstabelle Seite 150 Mit WZ 2.2 oder 3.1 und CE-Zeichen mm 2 3 4 5 6 10 p P P 12 p P P 15 p p p P 16 p P P 20 P P P 25 p P P 30 P P P 35 P P 40 P P P 45 P P 50 P P 60 p P P 70 P P 80 P P 90 p P 100 P P 110 p p P P 120 P P P 130 p p p p 140 p p p P 150 p p P P
Walzstahl 133 P Lagervorrat p kurzfristig lieferbar S 235 JR EN 10025 Länge: 6 m Flachstahl Plats / Flats Gewichte siehe Gewichtstabelle Seite 150 Mit WZ 2.2 oder 3.1 und CE-Zeichen Profilstahl sägen wir auf Wunsch auf Ihr Fixmaß. Reststücke müssen übernommen werden. mm 5 6 8 10 12 15 20 25 30 35 40 50 60 10 P 12 P P P 15 P P P 16 P P P P 18 P P P p 20 P P P P P P 25 P P P P P P p 30 P P P P P P P p 35 P P P P P P P p 40 P P P P P P P P P 45 P P P P P P p 50 P P P P P P P P P P 55 P P P P P P P 60 P P P P P P P P P p P P 65 P P P P P P p 70 P P P P P P P P P p P P 75 P P P P P P p 80 P P P P P P P P P p P P P 90 P P P P P P P P P P p p 100 P P P P P P P P P P P P P 110 P P P P P P P p p p 120 P P P P P P P P P P 130 P P P P P P P P P 140 P P P P P P P P P 150 P P P P P P P P P P
Walzstahl 134 P Lagervorrat p kurzfristig lieferbar S 235 JR EN 10025 DIN 59200 Länge: 6 m Breitflachstahl Larges plats / Universal plates Breitflachstahl sägen wir auf Wunsch auf Ihr Fixmaß. Gewichte siehe Gewichtstabelle „Gewichtstabelle I.“ auf Seite 150. Breitflachstahl liefern wir auch in allen anderen von Ihnen gewünschten Abmessungen, Lagerlängen (auch 12 m) Fixlängen und Güten, in geschnittener bzw. gebrannter Ausführung. Mit WZ 2.2 oder 3.1 und CE-Zeichen mm 5 6 8 10 12 15 20 25 30 40 50 160 p P P P P P P P P P 170 p P P P P P 180 p P P P P P P P P P 190 p p p p P p 200 p P P P P P P P P P p 220 p p P P P P P P P 230 p p p p p p 240 p p P P P P 250 p P P P P P P P P p 260 p p P P P P p p p 280 p p P p P P 300 p P P P P P P P P p p 320 p p p p p p p p p 350 p p P p P P p p p p 380 p p p p p p p 400 p p P p P P p p p p 450 p p p p p p p p p 500 p p P p P P p p p p 600 p p p p p p p p p p
Walzstahl 135 P Lagervorrat p kurzfristig lieferbar S 235 JR EN 10025 Herstellungslänge: 6 m u. 12 m Mit WZ 2.2 oder 3.1 und CE-Zeichen Profilstahl sägen wir auf Wunsch auf Ihr Fixmaß. Reststücke müssen übernommen werden. Gleichschenkliger Winkelstahl Cornières à ailes égales / Equal-leg angles mm kg/m 20 x 20 x 3 0,88 P 20 x 20 x 4 1,14 P 25 x 25 x 3 1,12 P 25 x 25 x 4 1,45 P 25 x 25 x 5 1,77 P 30 x 30 x 3 1,36 P 30 x 30 x 4 1,78 P 30 x 30 x 5 2,18 P 35 x 35 x 3 1,60 p 35 x 35 x 4 2,10 P 35 x 35 x 5 2,57 P 35 x 35 x 6 3,04 p 40 x 40 x 3 1,84 P 40 x 40 x 4 2,42 P 40 x 40 x 5 2,97 P 40 x 40 x 6 3,52 P 45 x 45 x 4 2,74 p 45 x 45 x 5 3,38 P 45 x 45 x 6 4,00 p 45 x 45 x 7 4,60 p 50 x 50 x 4 3,06 P 50 x 50 x 5 3,77 P 50 x 50 x 6 4,47 P 50 x 50 x 7 5,15 P 50 x 50 x 8 5,82 P 50 x 50 x 9 6,47 p mm kg/m 55 x 55 x 5 4,18 p 55 x 55 x 6 4,95 P 55 x 55 x 8 6,46 p 60 x 60 x 5 4,57 P 60 x 60 x 6 5,42 P 60 x 60 x 8 7,09 P 60 x 60 x 10 8,69 P 65 x 65 x 6 5,91 p 65 x 65 x 7 6,83 P 65 x 65 x 8 7,73 p 65 x 65 x 9 8,62 p 70 x 70 x 6 6,38 P 70 x 70 x 7 7,38 P 70 x 70 x 9 9,34 P 70 x 70 x 10 11,2 p 75 x 75 x 7 7,94 p 75 x 75 x 8 9,03 P 75 x 75 x 10 11,1 P 80 x 80 x 6 7,84 P 80 x 80 x 7 8,49 p 80 x 80 x 8 9,66 P 80 x 80 x 10 11,9 P 80 x 80 x 11 14,1 p 80 x 80 x 12 14,0 P 90 x 90 x 9 12,2 P 90 x 90 x 11 14,7 p
Walzstahl 136 P Lagervorrat p kurzfristig lieferbar S 235 JR EN 10025 Herstellungslänge: 6 m u. 12 m Mit WZ 2.2 oder 3.1 und CE-Zeichen Profilstahl sägen wir auf Wunsch auf Ihr Fixmaß. Reststücke müssen übernommen werden. Gleichschenkliger Winkelstahl Cornières à ailes égales / Equal-leg angles mm kg/m 100 x 100 x 8 12,2 P 100 x 100 x 10 15,1 P 100 x 100 x 12 17,8 P 100 x 100 x 14 20,6 p 100 x 100 x 16 23,2 p 110 x 110 x 10 16,6 P 110 x 110 x 13 19,7 p 120 x 120 x 11 19,9 P 120 x 120 x 12 21,6 P 120 x 120 x 13 23,3 p 120 x 120 x 14 26,6 p 130 x 130 x 12 23,6 P 130 x 130 x 14 27,2 p 140 x 140 x 13 27,5 P 140 x 140 x 15 31,4 p 150 x 150 x 12 27,3 P 150 x 150 x 13 31,6 p 150 x 150 x 15 33,8 P 150 x 150 x 16 35,9 p 150 x 150 x 18 40,1 p 150 x 150 x 20 44,2 p 160 x 160 x 15 36,2 P 160 x 160 x 17 40,7 p 160 x 160 x 19 45,1 p 180 x 180 x 16 43,5 p 180 x 180 x 18 48,6 P mm kg/m 180 x 180 x 20 53,7 p 200 x 200 x 16 48,5 P 200 x 200 x 18 54,3 p 200 x 200 x 20 59,9 P 200 x 200 x 24 71,1 p
Walzstahl 137 P Lagervorrat p kurzfristig lieferbar S 235 JR EN 10025 Herstellungslänge: 6 m u. 12 m Ungleichschenkliger Winkelstahl Cornières à ailes inégales / Unequal-leg angles Mit WZ 2.2 oder 3.1 und CE-Zeichen Profilstahl sägen wir auf Wunsch auf Ihr Fixmaß. Reststücke müssen übernommen werden. mm kg/m 30 x 20 x 3 1,11 P 30 x 20 x 4 1,45 P 40 x 20 x 3 1,35 P 40 x 20 x 4 1,77 P 45 x 30 x 3 1,72 p 45 x 30 x 4 2,25 P 45 x 30 x 5 2,77 P 50 x 30 x 5 2,96 P 50 x 40 x 4 2,71 P 50 x 40 x 5 3,35 P 60 x 30 x 5 3,37 P 60 x 30 x 6 3,98 P 60 x 30 x 7 4,59 P 60 x 40 x 5 3,76 P 60 x 40 x 6 4,46 P 60 x 40 x 7 5,14 P 65 x 50 x 5 4,35 P 65 x 50 x 7 5,97 P 65 x 50 x 9 7,52 p 75 x 50 x 5 4,74 P 75 x 50 x 7 6,51 P 75 x 50 x 9 8,23 p 75 x 55 x 5 4,95 P 75 x 55 x 7 6,80 P 75 x 55 x 9 8,59 p 80 x 40 x 6 5,41 P mm kg/m 80 x 40 x 8 7,07 P 80 x 65 x 6 6,60 P 80 x 65 x 8 8,66 P 80 x 65 x 10 10,7 P 90 x 60 x 6 6,82 P 90 x 60 x 8 8,96 P 100 x 50 x 6 6,85 P 100 x 50 x 8 8,99 P 100 x 50 x 10 11,1 P 100 x 65 x 7 8,77 P 100 x 65 x 9 11,1 P 100 x 65 x 11 13,4 P 100 x 75 x 7 9,32 P 100 x 75 x 9 11,8 P 100 x 75 x 11 14,3 p 120 x 80 x 8 12,2 P 120 x 80 x 10 15,0 P 120 x 80 x 12 17,8 P 120 x 80 x 14 20,5 p 130 x 65 x 8 11,9 P 130 x 65 x 10 14,6 P 130 x 65 x 12 17,3 p 130 x 90 x 10 16,6 P 130 x 90 x 12 19,7 p 150 x 75 x 9 15,3 P 150 x 90 x 10 18,2 P
Walzstahl 138 P Lagervorrat p kurzfristig lieferbar S 235 JR EN 10025 Herstellungslänge: 6 m u. 12 m Ungleichschenkliger Winkelstahl Cornières à ailes inégales / Unequal-leg angles Mit WZ 2.2 oder 3.1 und CE-Zeichen Profilstahl sägen wir auf Wunsch auf Ihr Fixmaß. Reststücke müssen übernommen werden. mm kg/m 150 x 90 x 12 21,6 p 150 x 100 x 10 19,0 P 150 x 100 x 12 22,6 P 150 x 100 x 14 26,1 p 160 x 80 x 10 18,2 P 160 x 80 x 12 21,6 P 160 x 80 x 14 25,0 p 180 x 90 x 10 20,6 P 180 x 90 x 12 24,5 p 180 x 90 x 14 28,3 p 200 x 100 x 10 23,0 P 200 x 100 x 12 27,3 P 200 x 100 x 14 31,6 P 200 x 100 x 16 35,9 p 250 x 90 x 10 26,1 P 250 x 90 x 12 31,1 p 250 x 90 x 14 36,0 p 250 x 90 x 16 40,9 p
Walzstahl 139 P Lagervorrat p kurzfristig lieferbar S 235 JR EN 10025 T-Stahl Profils en T / T-sections Mit WZ 2.2 oder 3.1 und CE-Zeichen Profilstahl sägen wir auf Wunsch auf Ihr Fixmaß. Reststücke müssen übernommen werden. kg/m 6 m 12 m T 20/3 0,88 P T 25/3,5 1,29 P T 30/4 1,77 P T 35/4,5 2,33 P T 40/5 2,96 P T 45/5,5 3,67 P kg/m 6 m 12 m U 30 (30/33) 4,27 P U 40 (40/35) 4,87 P U 50 (50/38) 5,59 P U 65 (65/42) 7,09 P P kg/m 6 m 12 m T 50/6 4,44 P T 60/7 6,23 P T 70/8 8,32 P T 80/9 10,70 P T 90/10 13,40 p P T 100/11 16,40 P P T 120/12 23,20 P T 140/15 31,30 P S 235 JR EN 10025 U-Stahl Profils en U / Channel sections kg/m 6 m 12 m U 30/15/4 1,79 P U 40/20/5 2,87 P U 50/25/5 3,86 P U 60/30/6 5,07 P
Walzstahl 140 P Lagervorrat p kurzfristig lieferbar Verzinkter U-Stahl Profils en U galvanisés/ Channel sections galvanized kg/m U-40/35 5,16 P U-50/38 6,05 P U-60/30 5,58 P U-65/42 7,52 P Verzinkter Winkelstahl Cornières galvanisés/ Angles galvanized Weitere Abmessungen auch im Präge-Bereich kurzfristig lieferbar! kg/m 20/20/3 0,97 P 25/25/3 1,21 P 30/20/3 1,20 P 30/30/3 1,47 P 35/35/4 2,24 P 40/20/4 1,54 P 40/40/4 2,58 P 40/40/5 3,21 P kg/m 50/50/5 3,98 P 60/30/5 3,56 P 60/60/6 5,67 P 70/70/7 7,75 P 80/40/6 5,73 P 80/80/8 10,14 P 100/50/6 7,19 P 100/100/10 16,30 P S 235 JR EN 10025 Herstellungslänge: 6 m S 235 JR EN 10025 Herstellungslänge: 6 m
Walzstahl 141 P Lagervorrat p kurzfristig lieferbar Verzinkter Rundstahl Ronds galvanisés / Galvanized rounds S 235 JR EN 10025 Länge: 6 Meter Ø kg/m 8 0,410 P 10 0,640 P 12 0,910 P 14 1,280 P Profilstahl sägen wir auf Wunsch auf Ihr Fixmaß. Reststücke müssen übernommen werden. kg/m 20 x 3 0,51 P 25 x 3 0,59 P 30 x 3 0,76 P 30 x 4 1,02 P 30 x 5 1,25 P 30 x 6 1,5 P 35 x 6 1,78 P 40 x 4 1,36 P 40 x 5 1,66 P 40 x 6 1,88 P 40 x 8 2,71 P 50 x 5 2,07 P S 235 JR EN 10025 Länge: 6 Meter Verzinkter Flachstahl Plats galvanisés / Flats galvanized kg/m 50 x 6 2,36 P 50 x 8 3,30 P 50 x 10 4,24 P 60 x 5 2,53 P 60 x 6 3,06 P 60 x 8 4,07 P 60 x 10 5,09 P 80 x 6 3,96 P 80 x 8 5,27 P 80 x 10 6,59 P 90 x 6 4,57 P 100 x 80 6,59 P 100 x 10 8,32 P Ø kg/m 16 1,660 P 20 2,660 P
Walzstahl 142 P Lagervorrat p kurzfristig lieferbar in Ringen à ca. 50 kg Länge: 6 Meter Bandstahl verzinkt Feuillards galvanisés/ galvanized Strip material kg/m 30 x 3,5 p 30 x 4,0 p 40 x 4,0 p Verzinkter U-Stahl Profils en U galvanisés / Galvanized channels kg/m UNP 80 9,52 P UNP 100 11,66 P UNP 120 14,87 P
Walzstahl 143 P Lagervorrat p kurzfristig lieferbar UNP DIN 1026 Neigung der inneren Flanschflächen 8 % bei Profilen mit h ≤ 300 5 % bei Profilen mit h ≥ 300 Formstahl warmgewalzter, rundkantiger U-Stahl Poutrelles UNP / Hot rolled sections, round-edged channel Bezeichnung UNP Maße in mm Höhe h Breite b Stegdicke ts Flanschdicke tg Gewicht kg/m 80 P 80 45 6,0 8,0 8,9 100 P 100 50 6,0 8,5 10,9 120 P 120 55 7,0 9,0 13,7 140 P 140 60 7,0 10,0 16,4 160 P 160 65 7,5 10,5 19,3 180 P 180 70 8,0 11,0 22,5 200 P 200 75 8,5 11,5 26 220 P 220 80 9,0 12,5 30 240 P 240 85 9,5 13,0 34 260 P 260 90 10,0 14,0 39 280 P 280 95 10,0 15,0 43 300 P 300 100 10,0 16,0 48 320 p 320 100 14,0 17,5 61 350 p 350 100 14,0 16,0 62 380 p 380 102 13,5 19,0 65 400 p 400 110 14,0 18,0 74 z r1=tg ts r2 y ez XM h tg b z y b 2 h1=h-2c Unser Service für Sie: • Auf Wunsch alle Profile fix gesägt, mit engsten Toleranzen • gestrahlt sa 2,5 • gestrahlt sa 2,5 und geprimert rotbraun 15-20 µm • verzinkt (teilweise Bohrungen erforderlich) • Gehrungsschnitte auf Anfrage siehe „Schnittbilder für Formstahl/ Breitflanschträger“ auf Seite 149. Mit Wz 2.2 oder 3.1 und CE-Zeichen
Walzstahl 144 P Lagervorrat p kurzfristig lieferbar DIN 1025 Teil 1 / EN 10024 mit geneigten inneren Flanschflächen Schmale I-Träger INP Poutrelles INP / Narrow I-beams INP with sloping inner flange Bezeichnung INP mm Gewicht h b ts = r1 tg r2 kg/m 80 P 80 42 3,9 5,9 2,3 6,1 100 P 100 50 4,5 6,8 2,7 8,5 120 P 120 58 5,1 7,7 3,1 11,5 140 P 140 66 5,7 8,6 3,4 14,7 160 P 160 74 6,3 9,5 3,8 18,5 180 P 180 82 6,9 10,4 4,1 22,5 200 P 200 90 7,5 11,3 4,5 27 220 p 220 98 8,1 12,2 4,9 32 240 p 240 106 8,7 13,1 5,2 37 260 p 260 113 9,4 14,1 5,6 43 280 p 280 119 10,1 15,2 6,1 49 300 p 300 125 10,8 16,2 6,5 56 320 p 320 131 11,5 17,3 6,9 63 340 p 340 137 12,2 18,3 7,3 70 360 p 360 143 13,0 19,5 7,8 78 400 p 400 155 14,4 21,6 8,6 95 450 p 450 170 16,2 24,3 9,7 118 500 500 185 18,0 27,0 10,8 145 r2 s=r1 ts z y z b Neigung 14% h1=h-2c tg y h Unser Service für Sie: • Auf Wunsch alle Profile fix gesägt, mit engsten Toleranzen • gestrahlt sa 2,5 • gestrahlt sa 2,5 und geprimert rotbraun 15-20 µm • verzinkt (teilweise Bohrungen erforderlich) • Gehrungsschnitte auf Anfrage siehe „Schnittbilder für Formstahl/ Breitflanschträger“ auf Seite 149. Mit Wz 2.2 oder 3.1 und CE-Zeichen
Walzstahl 145 P Lagervorrat p kurzfristig lieferbar DIN 1025 Teil 5 / EN 10034 mit parallelen Flanschflächen Formstahl IPE Mittelbreite I-Träger IPE Poutrelles IPE / Medium-size-I-beams IPE with parallel flange Bezeichnung IPE mm Gewicht h b ts tg r kg/m 80 P 80 46 3,8 5,2 5 6,2 100 P 100 55 4,1 5,7 7 8,3 120 P 120 64 4,4 6,3 7 10,7 140 P 140 73 4,7 6,9 7 13,2 160 P 160 82 5,0 7,4 9 16,2 180 P 180 91 5,3 8,0 9 19,3 200 P 200 100 5,6 8,5 12 23 220 P 220 110 5,9 9,2 12 26,9 240 P 240 120 6,2 9,8 15 31,5 270 P 270 135 6,6 10,2 15 37 300 P 300 150 7,1 10,7 15 43,3 330 p 330 160 7,5 11,5 18 50,4 360 p 360 170 8,0 12,7 18 58,6 400 p 400 180 8,6 13,5 21 68 450 p 450 190 9,4 14,6 21 80 500 p 500 200 10,2 16,0 21 93 550 p 550 210 11,1 17,2 24 109 600 p 600 220 12,0 19,0 24 125 z b r ts y y z tg h=2c c=tg+r h K=h-2tg Unser Service für Sie: • Auf Wunsch alle Profile fix gesägt, mit engsten Toleranzen • gestrahlt sa 2,5 • gestrahlt sa 2,5 und geprimert rotbraun 15-20 µm • verzinkt (teilweise Bohrungen erforderlich) • Gehrungsschnitte auf Anfrage siehe„Schnittbilder für Formstahl/ Breitflanschträger“ auf Seite 149. Mit Wz 2.2 oder 3.1 und CE-Zeichen
Walzstahl 146 P Lagervorrat p kurzfristig lieferbar DIN 1025 Teil 2 / EN 10034 mit parallelen Flanschflächen Reihe HE-B = IPB Breite I-Träger (Breitflanschträger) Poutrelles HEB/IPB Wide I-beams (wide-flanged beams) with parallel flange Bezeichnung HE B mm Gewicht h b ts tg r kg/m 100 P 100 100 6,0 10,0 12 20,9 120 P 120 120 6,5 11,0 12 27,4 140 P 140 140 7,0 12,0 12 34,5 160 P 160 160 8,0 13,0 15 43,7 180 P 180 180 8,5 14,0 15 52,5 200 P 200 200 9,0 15,0 18 63 220 P 220 220 9,5 16,0 18 73 240 P 240 240 10,0 17,0 21 85 260 P 260 260 10,0 17,5 24 95 280 P 280 280 10,5 18,0 24 106 300 P 300 300 11,0 19,0 27 120 320 p 320 300 11,5 20,5 27 130 340 p 340 300 12,0 21,5 27 137 360 p 360 300 12,5 22,5 27 146 400 p 400 300 13,5 24,0 27 159 450 p 450 300 14,0 26,0 27 175 500 p 500 300 14,5 28,0 27 192 550 p 550 300 15,0 29,0 27 204 600 p 600 300 15,5 30,0 27 217 650 p 650 300 16,0 31,0 27 231 700 p 700 300 17,0 32,0 27 247 800 p 800 300 17,5 33,0 30 269 900 p 900 300 18,5 35,0 30 298 1000 p 1000 300 19,0 36,0 30 322 • Unser Service für Sie: • Auf Wunsch alle Profile fix gesägt, mit engsten Toleranzen • gestrahlt sa 2,5 • gestrahlt sa 2,5 und geprimert rotbraun 15-20 µm • verzinkt (teilweise Bohrungen erforderlich) • Gehrungsschnitte auf Anfrage siehe „Schnittbilder für Formstahl/ Breitflanschträger“ auf Seite 149. • Mit Wz 2.2 oder 3.1 und CE-Zeichen
Walzstahl 147 P Lagervorrat p kurzfristig lieferbar DIN 1025 Teil 3 / EN 10034 leichte Ausführung, mit parallelen Flanschflächen Reihe HE A = IPBL Breite I-Träger (Breitflanschträger) Poutrelles HEA / Wide I-beams (wide-flanged beams) light version with parallel flange Bezeichnung HEA mm Gewicht h b ts tg r kg/m 100 P 95 100 5,0 8,0 12 17,1 120 P 114 120 5,0 8,0 12 20,4 140 P 133 140 5,5 8,5 12 25,3 160 P 152 160 6,0 9,0 15 31,2 180 P 171 180 6,0 9,5 15 36,4 200 P 190 200 6,5 10,0 18 43 220 P 210 220 7,0 11,0 18 52 240 P 230 240 7,5 12,0 21 62 260 P 250 260 7,5 12,5 24 70 280 P 270 280 8,0 13,0 24 78 300 P 290 300 8,5 14,0 27 90 320 p 310 300 9,0 15,5 27 100 340 p 330 300 9,5 16,5 27 108 360 p 350 300 10,0 17,5 27 115 400 p 390 300 11,0 19,0 27 128 450 p 440 300 11,5 21,0 27 143 500 p 490 300 12,0 23,0 27 159 550 p 540 300 12,5 24,0 27 170 600 p 590 300 13,0 25,0 27 182 650 p 640 300 13,5 26,0 27 195 700 p 690 300 14,5 27,0 27 209 800 p 790 300 15,0 28,0 30 230 900 p 890 300 16,0 30,0 30 258 1000 p 990 300 16,5 31,0 30 279 y y h-2c c=tg+r K=h-2tg r z z b tg ts h Unser Service für Sie: • Auf Wunsch alle Profile fix gesägt, mit engsten Toleranzen • gestrahlt sa 2,5 • gestrahlt sa 2,5 und geprimert rotbraun 15-20 µm • verzinkt (teilweise Bohrungen erforderlich) • Gehrungsschnitte auf Anfrage siehe„Schnittbilder für Formstahl/Breitflanschträger“ auf Seite 149. Mit Wz 2.2 oder 3.1 und CE-Zeichen
Walzstahl 148 P Lagervorrat p kurzfristig lieferbar DIN 1025 Teil 4 / EN 10034 Reihe HE-M = IPBv verstärkte Ausführung, mit parallelen Flanschflächen Breite I-Träger (Breitflanschträger) Poutrelles HEM / Wide I-beams (wide-flanged beams) enhanced version, with parallel flange Bezeichnung HE M mm Gewicht h b ts tg r kg/m 100 P 120 106 12,0 20,0 12 42,8 120 P 140 126 12,5 21,0 12 53,4 140 P 160 146 13,0 22,0 12 64,8 160 P 180 166 14,0 23,0 15 78,1 180 P 200 186 14,5 24,0 15 91,1 200 P 220 206 15,0 25,0 18 106 220 P 240 226 15,5 26,0 18 120 240 P 270 248 18,0 32,0 21 161 260 P 290 263 18,0 32,5 24 176 280 p 310 288 18,5 33,0 24 194 300 P 340 310 21,0 39,0 27 244 320 p 359 309 21,9 40,0 27 251 340 p 377 309 21,0 40,0 27 254 360 p 395 308 21,0 40,0 27 256 400 p 432 307 21,0 40,0 27 262 450 p 478 307 21,0 40,0 27 270 500 p 524 306 21,0 40,0 27 277 550 p 572 306 21,0 40,0 27 285 600 p 620 305 21,0 40,0 27 292 650 p 668 306 21,0 40,0 27 300 700 p 716 304 21,0 40,0 27 309 800 p 814 303 21,0 40,0 30 325 900 p 910 302 21,0 40,0 30 341 1000 p 1008 302 21,0 40,0 30 358 y y h-2c c=tg+r K=h-2tg r z z b tg ts h Unser Service für Sie: • Auf Wunsch alle Profile fix gesägt, mit engsten Toleranzen • gestrahlt sa 2,5 • gestrahlt sa 2,5 und geprimert rotbraun 15-20 µm • verzinkt (teilweise Bohrungen erforderlich) • Gehrungsschnitte auf Anfrage siehe„Schnittbilder für Formstahl/ Breitflanschträger“ auf Seite 149. Mit Wz 2.2 oder 3.1 und CE-Zeichen
Walzstahl 149 P Lagervorrat p kurzfristig lieferbar Schnittbilder für Formstahl/Breitflanschträger Coupes transversales / Cross sections
Walzstahl 150 Gewichtstabelle I. Tableau des poids / table of weight Rund- und Vierkantstahl Gewichte in kg pro Meter d d d mm rund vierkt. 2,5 0,04 0,05 3 0,06 0,07 3,5 0,08 0,10 4 0,10 0,13 4,5 0,13 0,16 5 0,15 0,20 5,5 0,19 0,24 6 0,22 0,28 7 0,30 0,38 8 0,39 0,50 9 0,50 0,64 10 0,62 0,78 11 0,75 0,95 12 0,89 1,13 13 1,04 1,33 14 1,21 1,54 15 1,39 1,77 16 1,58 2,01 17 1,78 2,27 18 2,00 2,54 19 2,23 2,83 20 2,47 3,14 21 2,72 3,46 22 2,98 3,80 23 3,26 4,15 24 3,55 4,52 25 3,85 4,91 26 4,17 5,31 27 4,50 5,72 28 4,83 6,15 d d d mm rund vierkt. 29 5,19 6,61 30 5,55 7,07 31 5,92 7,54 32 6,31 8,04 33 6,71 8,55 34 7,13 9,07 35 7,55 9,62 36 7,99 10,2 37 8,44 10,7 38 8,90 11,3 39 9,38 11,9 40 9,87 12,6 41 10,4 13,2 42 10,9 13,9 45 12,5 15,9 46 13,0 16,6 48 14,2 18,1 50 15,4 19,6 53 17,3 22,1 55 18,7 23,8 58 20,7 26,4 60 22,2 28,3 63 24,5 31,2 65 26,0 33,2 68 28,5 36,3 70 30,2 38,5 73 32,9 41,8 75 34,7 44,2 78 37,5 47,8 80 39,5 50,2 d d d mm rund vierkt. 83 42,5 54,1 85 44,5 56,7 90 49,9 63,6 95 55,6 70,8 100 61,7 78,5 105 68,0 86,6 110 74,6 95,0 115 81,5 104 120 88,8 113 125 96,3 123 130 104 133 135 112 143 140 121 154 145 130 165 150 139 177 160 158 201 170 178 227 180 200 254 190 223 283 200 247 314 210 272 346 220 298 380 230 326 415 240 355 452 250 385 491 260 417 531 270 450 572 280 483 615 290 519 660 300 555 707 400 986 1256 500 1541 1962
Walzstahl 151 Gewichtstabelle II. Tableau des poids / table of weight Breite in mm 2 3 4 5 6 7 8 9 10 12 14 15 16 18 20 25 30 32 35 40 50 60 6 8 10 12 13 14 15 16 18 20 22 24 25 26 28 30 32 35 36 40 45 50 55 60 63 65 70 75 80 90 100 110 120 125 130 140 150 160 180 200 220 250 300 400 0,09 0,13 0,16 0,19 0,20 0,22 0,24 0,25 0,28 0,31 0,34 0,38 0,39 0,41 0,44 0,47 0,50 0,55 0,75 0,63 0,71 0,78 0,86 0,94 0,99 1,02 1,10 1,18 1,26 1,41 1,57 1,73 1,88 1,96 2,04 2,20 2,36 2,51 2,83 3,14 3,45 3,93 4,71 6,28 0,14 0,19 0,24 0,28 0,31 0,33 0,35 0,38 0,42 0,47 0,52 0,57 0,59 0,61 0,66 0,71 0,75 0,82 0,85 0,94 1,06 1,18 1,30 1,41 1,48 1,53 1,65 1,77 1,88 2,12 2,36 2,59 2,83 2,94 3,06 3,30 3,53 3,77 4,24 4,71 5,18 5,89 7,07 9,42 0,19 0,25 0,31 0,38 0,41 0,44 0,47 0,50 0,57 0,63 0,69 0,75 0,79 0,82 0,88 0,94 1,00 1,10 1,13 1,26 1,41 1,57 1,73 1,88 1,98 2,02 2,20 2,26 2,51 2,83 3,14 3,45 3,77 3,93 4,08 4,40 4,71 5,02 5,65 6,28 6,91 7,85 9,42 12,56 0,24 0,32 0,39 0,47 0,51 0,55 0,59 0,63 0,71 0,79 0,86 0,94 0,93 1,02 1,10 1,18 1,26 1,37 1,41 1,57 1,77 1,96 2,16 2,36 2,47 2,55 2,75 2,94 3,14 3,53 3,93 4,32 4,71 4,91 5,10 5,50 5,89 6,28 7,07 7,85 8,64 9,81 11,80 15,70 0,38 0,47 0,57 0,61 0,66 0,71 0,74 0,85 0,94 1,04 1,13 1,18 1,23 1,32 1,41 1,51 1,65 1,70 1,88 2,12 2,36 2,59 2,83 2,97 3,06 3,30 3,53 3,77 4,24 4,71 5,18 5,65 5,89 6,12 6,50 7,07 7,54 8,48 9,42 10,36 11,8 14,1 18,8 0,44 0,55 0,66 0,71 0,77 0,82 0,88 0,99 1,10 1,21 1,32 1,37 1,43 1,54 1,65 1,76 1,92 1,98 2,20 2,47 2,75 3,02 3,30 3,46 3,57 3,85 4,12 4,40 4,95 5,50 6,04 6,59 6,87 7,14 7,69 8,24 8,79 9,89 10,99 12,0 13,7 16,4 21,9 0,63 0,75 0,82 0,88 0,94 1,01 1,13 1,26 1,38 1,51 1,57 1,63 1,76 1,88 2,01 2,20 2,26 2,51 2,83 3,14 3,45 3,77 3,96 4,08 4,40 4,71 5,02 5,65 6,28 6,91 7,54 7,85 8,16 8,79 9,42 10,1 11,3 12,6 13,8 15,7 18,8 25,1 0,71 0,85 0,92 0,99 1,06 1,13 1,27 1,41 1,55 1,70 1,77 1,84 1,98 2,12 2,26 2,47 2,54 2,83 3,18 3,53 3,89 4,24 4,45 4,59 4,95 5,30 5,65 6,36 7,07 7,77 8,48 8,83 9,18 9,89 10,6 11,3 12,7 14,1 15,5 17,7 21,2 28,2 0,94 1,02 1,10 1,18 1,26 1,41 1,57 1,73 1,88 1,96 2,04 2,20 2,36 2,51 2,75 2,83 3,14 3,53 3,93 4,32 4,71 4,95 5,10 5,50 5,89 6,28 7,07 7,85 8,64 9,42 9,81 10,2 11,00 11,8 12,6 14,1 15,7 17,2 19,6 23,6 31,4 1,22 1,32 1,41 1,51 1,70 1,88 2,07 2,26 2,36 2,45 2,64 2,83 3,01 3,30 3,39 3,77 4,24 4,71 5,18 5,65 5,93 6,12 6,59 7,07 7,54 8,48 9,42 10,4 11,3 11,7 12,3 13,2 14,1 15,1 17,0 18,8 20,7 23,6 28,3 37,6 1,65 1,76 1,98 2,20 2,42 2,64 2,75 2,86 3,08 3,30 3,52 3,85 3,96 4,40 4,95 5,50 6,05 6,59 6,92 7,14 7,69 8,24 8,79 9,89 11,0 12,1 13,2 13,7 14,3 15,4 16,5 17,6 19,8 22,0 24,1 27,5 33,0 43,9 1,88 2,12 2,36 2,59 2,83 2,94 3,06 3,30 3,53 3,77 4,12 4,24 4,71 5,30 5,89 6,48 7,07 7,42 7,65 8,24 8,83 9,42 10,6 11,8 13,0 14,1 14,7 15,3 16,5 17,7 18,8 21,2 23,6 25,9 29,4 35,3 47,1 2,26 2,51 2,76 3,01 3,14 3,27 3,52 3,77 4,02 4,40 4,52 5,02 5,65 6,28 6,91 7,54 7,91 8,16 8,79 9,42 10,0 11,3 12,6 13,8 15,1 15,7 16,3 17,6 18,8 20,1 22,6 25,1 27,6 31,4 37,7 50,2 2,83 3,11 3,39 3,53 3,67 3,96 4,24 4,52 4,95 5,09 5,65 6,36 7,07 7,77 8,48 8,90 9,18 9,89 10,6 11,3 12,7 14,1 15,5 17,0 17,6 18,4 19,8 21,2 22,6 25,4 28,3 31,0 35,3 42,3 56,5 3,45 3,77 3,93 4,08 4,40 4,71 5,02 5,50 5,65 6,28 7,07 7,85 8,64 9,42 9,89 10,2 11,0 11,8 12,6 14,1 15,7 17,3 18,8 19,6 20,4 22,0 23,6 25,1 28,3 31,4 34,5 39,3 47,1 62,8 5,50 5,89 6,28 6,87 7,07 7,85 8,83 9,81 10,80 11,80 12,3 12,8 13,7 14,7 15,7 17,7 19,6 21,6 23,6 24,5 25,5 27,5 29,4 31,4 35,3 39,3 43,1 49,1 58,9 78,5 7,54 8,24 8,48 9,42 10,60 11,78 13,01 14,13 14,8 15,3 16,5 17,7 18,8 21,2 23,6 25,9 28,3 29,4 30,6 33,0 35,3 37,7 42,4 47,1 54,1 58,9 70,7 94,2 8,79 9,04 10,05 11,30 12,56 13,82 15,07 15,8 16,3 17,5 18,8 20,1 22,6 25,1 27,6 30,1 31,4 32,6 35,1 37,6 40,1 45,2 50,2 55,2 62,8 75,3 100,5 11,0 12,4 13,7 15,1 16,5 17,3 17,9 19,2 20,6 22,0 24,7 27,5 30,2 33,0 34,3 35,7 38,5 41,2 44,0 49,5 55,0 60,4 68,7 82,4 109,9 14,2 15,7 17,3 18,8 19,8 20,4 22,0 23,6 25,1 28,3 31,4 34,5 37,7 39,2 40,8 44,0 47,1 50,2 56,5 62,8 69,1 78,5 94,2 125,6 21,6 23,6 24,7 25,5 27,5 29,4 31,4 35,3 39,3 43,2 47,1 49,1 51,0 55,0 58,9 62,8 70,7 78,5 86,4 98,1 118,0 157,0 37,7 42,4 46,8 51,8 56,5 58,9 61,3 66,0 70,7 75,4 84,8 94,2 103,6 118,0 141,0 188,4
Walzstahl 152 P Lagervorrat p kurzfristig lieferbar Winkelstahl gleichschenklig, scharfkantig Cornières à ailes égales à angles vifs Angles, equal-sided, sharp-edged In Längen von 6 m Maße in mm Gewicht kg/m a s 10 2 0,30 P 15 2 0,44 P 15 3 0,64 P 20 2 0,60 P 20 3 0,87 P 25 2 0,75 p 25 3 1,11 P 25 4 1,44 p 30 2 0,91 p 30 3 1,34 P Maße in mm Gewicht kg/m a s 30 4 1,76 p 35 3 1,58 P 35 4 2,07 p 40 3 1,81 P 40 4 2,39 P 40 5 2,94 p 45 5 3,34 p 50 3 2,38 P 50 4 3,01 p 50 5 3,73 P 60 3 2,76 p 60 4 3,65 p
Walzstahl 153 P Lagervorrat p kurzfristig lieferbar Winkelstahl ungleichschenklig, scharfkantig Cornières à ailes inégales à angles vifs Angles, equal-sided, sharp-edged Bodenbelagwinkelstahl Cornières à plancher / Flooring angles ProfilNummer Maße in mm Gewicht kg/m a b c d s 2442/1 40 40 15 10 5 2,82 p 2554 50 50 20 10 5 4,23 p 2857 50 50 20 12 5 4,60 p 2555 50 50 20 14 7 5,59 p 2607 50 50 20 17 7 5,70 p 65.010.0 50 50 20 17 10 5,90 P s In Längen von 6 m In Längen von 6 m Maße in mm Gewicht kg/m a b s 20 10 2 0,44 p 20 10 3 0,64 P 20 14 3 0,73 P 25 15 3 0,87 P 30 16 3 1,01 P 30 16 4 1,32 p 30 20 3 1,11 P 35 20 3 1,22 P 35 20 4 1,63 P 40 20 3 1,34 p 40 20 4 1,76 P 40 25 3 1,46 p Maße in mm Gewicht kg/m a b s 40 25 4 1,92 P 40 30 3 1,58 p 45 30 3 1,70 p 45 30 4 2,23 p 50 25 3 1,70 P 50 25 4 2,23 p 50 40 4 2,70 P 60 30 3 2,05 p 60 30 4 2,70 P 60 40 4 3,01 P 80 40 4 3,64 p
Walzstahl 154 P Lagervorrat p kurzfristig lieferbar T-Stahl gleichschenklig, scharfkantig Profils en T, à angles vifs T-sections, equal-sided, sharp-edged T-Stahl breitflanschig, scharfkantig Profils en T à large semelle, et angles vifs T sections, broad flanged, sharp edged In Längen von 6 m In Längen von 6 m Maße in mm Gewicht kg/m b h s 28 14 2 0,63 p 30 20 3 1,11 p 40 20 3 1,35 p 50 25 4 2,23 p 60 39 4 3,10 p Maße in mm Gewicht kg/m b h s 20 20 3,0 0,87 p 25 25 3,5 1,26 p 30 30 3,0 1,34 p 30 30 4,0 1,50 p Maße in mm Gewicht kg/m b h s 35 35 4,0 2,07 p 40 40 4,0 2,39 p 40 40 5,0 2,95 P 50 50 5,0 3,73 p
Walzstahl 155 P Lagervorrat p kurzfristig lieferbar T-Stahl mit versetztem Steg, scharfkantig Profils en T ame désaxée à angles vifs T sections offset web, sharp edged T-Stahl breitflanschig, rundkantig Profils en T à large semelle, et angles arrondis T sections broad flanged, round edged In Längen von 6 m Maße in mm Gewicht kg/m b h s c 40 30 3 12 1,58 p 50 35 4 12 2,54 p Maße in mm Gewicht kg/m b h s 40 20 4,5 2,10 P 50 25 5,0 2,80 P 60 30 5,5 3,64 P 70 35 6,0 4,66 P 80 40 7,0 6,21 P 100 50 8,5 9,42 P 120 60 10,0 13,40 p
Walzstahl 156 P Lagervorrat p kurzfristig lieferbar Z-Stahl scharfkantig Profils en Z, à angles vifs Sections en Z, sharp-edged Z-Stahl rundkantig Profils en Z angles arrondis Z sections round edged In Längen von 6 m In Längen von 6 m Maße in mm Gewicht kg/m a b c s 9 20 13 3,0 0,84 p 16 25 25 3,5 1,62 p 25 16 16 3,0 1,20 p 30 16 13 4,0 1,60 p 30 35 17 4,0 2,32 p 35 20 16 4,5 2,19 p 35 30 18 3,0 1,82 p 40 22 17 4,5 2,47 p 40 35 25 3,0 2,18 p 40 35 25 4,0 2,90 P 50 25 18 3,0 2,05 p Maße in mm Gewicht kg/m a b c1 s1 s2 30 38 38 4,0 4,5 3,38 P 40 40 40 4,5 5,0 4,26 P 48 50 25 4,0 4,0 3,65 p 50 43 43 5,0 5,5 5,31 P 54 50 25 4,0 4,0 3,81 p 60 45 45 5,0 6,0 6,21 P 80 50 50 6,0 7,0 8,71 p 100 55 55 6,5 8,0 11,40 p 120 60 60 7,0 9,0 14,30 p 140 65 65 8,0 10,0 18,00 p 160 70 70 8,5 11,0 21,60 p
Walzstahl 157 P Lagervorrat p kurzfristig lieferbar U-Stahl scharfkantig Profils en U à angles vifs Channels sharp edged In Längen von 6 m Rolladen-U-Stahl scharfkantig Profils en U pour portières à angles vifs Channels for roller shutters sharp edged In Längen von 6 m Maße in mm Gewicht kg/m h h s 20 15 2,50 0,88 p 40 24 3,25 2,08 P 50 25 3,00 2,21 p 50 30 3,25 2,65 p 50 30 4,00 3,26 P 60 30 3,00 2,72 P 60 38 4,00 4,07 P Maße in mm Gewicht kg/m h b s 12 12 2,0 0,51 p 15 15 1,5 0,47 P 15 20 1,5 0,61 p 16 16 2,0 0,70 p 20 20 2,0 0,88 P 25 25 2,0 1,11 P 25 25 2,5 1,37 p 30 30 2,0 1,35 P 30 30 2,5 1,66 P 30 30 3,0 1,98 p 33 33 3,0 2,19 p 36 36 3,0 2,40 p 40 40 3,0 2,68 P 40 40 3,5 3,11 p 50 50 4,0 4,46 P 60 55 5,0 6,28 p
Walzstahl 158 P Lagervorrat p kurzfristig lieferbar Hespen- bzw. Gitterstahl Profils en U pour grillage Channels for fences/grids In Längen von 6 m Halbrund- und Flachhalbrundstahl Demi-ronds et demi-ronds aplatis Half-rounds and flat halfrounds In Längen von 6 m Maße in mm Gewicht kg/m a b s 30 8 4 1,24 P 40 12 5 2,25 P Maße in mm Gewicht kg/m a b 16 3,0 0,28 p 16 8,0 0,79 p 20 10,0 1,23 P 30 15,0 2,75 P 40 10,0 2,22 p 40 20,0 4,92 P 50 25,0 7,65 p 60 30,0 11,00 p 75 37,5 17,00 p
Walzstahl 159 P Lagervorrat p kurzfristig lieferbar Bezeichnung Gewicht kg/m Obergurt 120 mm 5,78 p Untergurt 80 mm 5,77 p Handleistenstahl Profils pour main-courante Banister steel 18 In Längen von 6 m Handlaufstahl abgeschrägt Profilés pour main-courante chanfreinés Banister steel bevelled In Längen von 6 m Brückenhandlauf Parapets de ponts Bridge rails Profilnummer Breite mm Gewicht kg/m 680 40 3,35 P 681 50 5,30 P Profilnummer Maße in mm Gewicht kg/m a b c 2457 45 8 5 2,61 p
Walzstahl 160 P Lagervorrat p kurzfristig lieferbar S = Standard Profilnummer Maße in mm Gewicht kg/m Traglast Gewicht (b) h h1 b1 2890 S 0 86,5 36,0 7,0 12,0 10,5 ≈ 0,5 p 2867 S1 103,2 40,0 7,7 16,2 14,8 ≈ 1,0 p 2810 S 2 121,3 41,0 10,8 21,3 20,9 ≈ 2,0 p 2811 S 3 135,4 53,0 12,7 23,0 28,6 ≈ 3,0 p 2862 S 4 157,2 61,2 14,0 24,4 36,0 ≈ 4,0 p 2891 S 5 175,0 66,2 16,2 25,6 42,8 ≈ 5,0 p 2757 S 6 201,5 71,2 19,4 25,7 52,3 ≈ 6,0 p Hubschienenprofile U-Standard Coulisses d’élévateur Lifting rail profiles 18 Mn B6 Hubschienenprofile I-Standard Coulisses d’élévateur Lifting rail profiles 18 Mn B6 In Herstellungslängen von 10 bis 12 m bzw. in Fixlängen In Herstellungslängen von 10 bis 12 m bzw. in Fixlängen S = Standard Profilnummer Maße in mm Gewicht kg/m Traglast Gewicht (b) h s b1 3018 S1 98,0 65,0 9,0 14,00 19,4 ≈ 1 p 3019 S2 113,9 66,0 11,0 18,00 25,3 ≈ 2 p 3275 129,6 72,0 12,0 20,50 31,2 ≈ 3 p 3020 S3 129,6 81,0 12,0 20,50 34,0 ≈ 3 p 3100 S4 152,4 83,0 14,0 22,00 40,8 ≈ 4 p 2912 140,2 69,9 12,7 18,96 31,0 ≈ 3 p
Walzstahl 161 P Lagervorrat p kurzfristig lieferbar Treppenschutzschiene Bordure de protection d’escaliers Stair nosing Markisenstahl Coulisses pour stores Awning rails In Längen von 6 m In Längen von 6 m Trennwandprofil (kaltprofiliert) Profil pour parois de séparation (façonnées à froid) Partition profile (cold shaped) Verzinkte Ausführung siehe C-Profile In Längen von 6 m Breite mm Gewicht kg/m 35 1,63 p Profilnummer Gewicht kg/m 1652/30 x 30 x 8,9 x 2,5 1,97 p Profilnummer Gewicht kg/m 2583/30 x 30 x 10 x 2 1,53 P
Walzstahl 162 P Lagervorrat p kurzfristig lieferbar C-Profile (kaltprofiliert) Profils en C (façonnées à froid) C sections (cold shaped) In Längen von 6 m C-Profile (kaltprofiliert) verzinkt Profils en C (façonnées à froid) galvanisées C sections (cold shaped) galvanized In Längen von 6 m Maße in mm Gewicht h b c s kg/m 30 30 10 2 1,58 p 40 40 12 3 3,02 p 50 50 15 4 4,94 p Maße in mm Gewicht h b c s kg/m 27 12 7,5 2,5 1,10 p 40 40 12,0 3,0 2,83 p 50 50 15,0 4,0 4,65 p 60 40 15,0 3,0 3,60 P 80 40 15,0 3,0 4,19 P 100 40 15,0 3,0 4,66 p 120 40 15,0 3,0 5,13 P 140 40 15,0 3,0 5,60 p 160 40 15,0 3,0 5,90 p 180 40 15,0 3,0 6,55 p 200 40 15,0 3,0 6,75 P
Walzstahl 163 P Lagervorrat p kurzfristig lieferbar U-Baustahl mit runden Kanten innen und außen Profils en U de construction U shaped constructional steel S 235 JR / EN 10162 In Längen von 6 m Bordwand-U-Profile In Längen von 6 m Maße in mm Gewicht kg/m h b s 18 21 1,5 0,65 p 20 20 1,5 0,65 P 23 23 1,5 0,76 P 25 25 1,5 0,83 P 28 28 1,5 0,92 P 30 30 1,5 0,99 P 30 30 2,0 1,31 P 36 36 3,0 2,29 P 40 40 2,0 1,78 p Maße in mm Gewicht kg/m h b s 40 18 3 1,54 p 40 20 3 1,63 P 40 25 3 1,89 p 40 35 4 2,96 P 40 40 3 2,55 P 46 45 3 2,92 P 50 40 4 3,65 P 50 50 4 4,22 P 54 45 4 4,03 P 62 45 4 4,30 P 65 50 5 5,78 p 70 50 4 4,85 P 80 45 5 5,98 p 80 50 4 5,21 P Maße in mm Gewicht kg/m h b s 80 50 5 6,30 P 80 70 5 7,95 p 90 50 5 6,70 P 100 50 5 7,05 P 100 50 6 8,45 p 100 70 6 10,30 p 108 55 5 7,80 p 120 55 6 9,75 p 120 60 6 10,20 P 140 60 6 11,10 P 160 65 6 12,60 P 160 65 7 14,40 p 200 80 6 15,90 P
Walzstahl 164 P Lagervorrat p kurzfristig lieferbar Scheuerleisten Listons de défense Skirtings U-Stahl (kaltprofiliert) sendzimir-verzinkt Profils en U (façonnées à froid), galvanisès „Sendzimir“ Channels (cold shaped) „Sendzimir“-galvanized In Längen von 6 m d s In Längen von 6 m Kipper-Z-Profile Profils en Z pour bennes basculantes Z sections for tip trucks In Längen von 6 m Profilnummer Maße in mm Gewicht kg/m a b c s 2506 31 40 42,5 3 2,83 p 2503 34 45 58,0 3 4,40 p Profilnummer Maße in mm Gewicht kg/m a b c d s 3076 40 50 30 10 2,0 1,86 p 2604 50 70 35 10 2,5 3,00 p Maße in mm Gewicht kg/m h b s 18 21 1,5 0,65 p 20 20 1,5 0,65 P 23 23 1,5 0,76 P 25 25 1,5 0,83 P 28 28 1,5 0,92 P 30 30 1,5 0,99 P
Walzstahl 165 Aufbau des Bezeichnungssystems für Stähle nach EN 10027-1 / EN 10027-2 / DIN V 17006-100
Walzstahl 166 Aufbau des Bezeichnungssystems für Stähle nach EN 10027-1 / EN 10027-2 / DIN V 17006-100
Walzstahl 167 Aufbau des Bezeichnungssystems für Stähle nach EN 10027-1 / EN 10027-2 / DIN V 17006-100
Walzstahl 168 Garagenroste Grilles pour revêtement de remises Garage paving grills Norm-Gitterroste mit Winkeleisenzargen Grilles normalisées / Standard grills Gitterrost mit quadratischen Maschen 30 x 30 mm SpezialWinkeleisenzargen mit Wulst Gitterrost mit rechteckigen Maschen 30 x 10 mm Abmessungen und Hilfen für Ihre Bestellung Treppenstufen Grilles pour marches d’escalier Doorstep grills
Walzstahl 169 Stifte Drähte Schweißgitter Zaunpfosten Doppelstabmatten Drahtgeflechte Wellengitter
Walzstahl 170 Stärke in mm: 1,0 1,2 1,4 1,6 1,8 2,0 2,2 2,5 2,8 3,1 4,0 5,0 6,0 1 kg = ca. lfm: 161 112 83 62 50 40 33 25 20 16 10 6,5 4,5 Pressendraht: geglüht, verzinkt geölt, ungeölt in 40 kg und 20 kg Spulen blank, geglüht Ballen-Ösendraht mit 1 Öse in jeder gewünschten Länge Ferner liefern wir: 4eck. Drahtgeflecht 6eck. Drahtgeflecht Casanet punktgeschweißtes Gitter am Stück verzinkt, kunststoffummantelt Drahtgewebe Fliegengewebe Wellstäbe für Weinbau und Garten Drahtstifte Gartentore Forstknotengeflechte Gabionen Stacheldrähte Schmuckzäune Zackenleiste zum Anschweißen Zackenleisten h = 42 mm, lg= 2 m, t = 3 mm, Zackenhöhe = 20 mm, Zackenabstand = 24 mm Draht/Drahterzeugnisse Fil étiré, tréfilés / Drawn wire, wire products Drähte blank, geglüht, verzinkt, starkverzinkt, kunststoffummantelt Stacheldrähte
Walzstahl 171 Doppelstabmatten Typ 8-8-6 Maschenweite: ca. 50 x 200 mm Mattenbreite: ca. 2500 mm Höhen: von 600 mm bis 2400 mm (in 200 mm Abständen) Oberfläche in: blank, feuerverzinkt, feuerverzinkt + beschichtet in versch. RAL-Farben, galvanisch verz. auf Anfrage Doppelstabmatten Typ 6-6-5 Maschenweite: ca. 50 x 200 mm Höhen: von 600 mm bis 2000 mm (in 200 mm Abständen) Oberfläche in: blank, feuerverzinkt, feuerverzinkt + beschichtet in versch. RAL-Farben, galvanisch verz. auf Anfrage Pfähle und Eck-Pfähle für DSM: Ausführung mit: Schelle, Klemmplatte, Profilschiene oder Flacheisen Oberfläche in: blank, feuerverzinkt, feuerverzinkt + beschichtet in versch. RAL-Farben, galvanisch verz. auf Anfrage Pfähle können einbetoniert oder aufgedübelt (mit Bodenplatte) werden. Zubehör DSM: Sichtschutzstreifen stabil/flexibel, Sicherheitshandlauf Lieferzeiten auf Anfrage Doppelstabmatten Clotures métalliques à barres doubles / Double stick mats
Walzstahl 172 Ausführung in: blank, verzinkt, Edelstahl 1.4301 Maschenweite in mm Drahtstärke Stückgröße 10 x 10 2 2000 x 1000 10 x 10 2 2500 x 1250 15 x 15 2,5 2000 x 1000 20 x 20 2,5 2000 x 1000 20 x 20 2,5 2500 x 1250 20 x 20 2,5 3000 x 2000 30 x 30 3 2000 x 1000 30 x 30 3 2500 x 1250 30 x 30 3 3000 x 1500 Wellengitter Treillis métallique tissé / Woven wire mesh Maschenweite in mm Drahtstärke Stückgröße 30 x 30 3 3000 x 2000 40 x 40 4 2000 x 1000 40 x 40 4 2500 x 1250 40 x 40 4 3000 x 2000 50 x 50 4 2000 x 1000 50 x 50 4 3000 x 2000 50 x 50 5 2000 x 1000 50 x 50 5 2500 x 1250 50 x 50 5 3000 x 2000 Ausführung in: blank, verzinkt, Edelstahl 1.4301 Maschenweite in mm Drahtstärke Stückgröße 20 x 20 2,5 2000 x 1000 25 x 25 3 2000 x 1000 25 x 25 3 2500 x 1250 25 x 25 3 3000 x 1500 30 x 30 3 2000 x 1000 30 x 30 3 3000 x 1500 40 x 40 4 2000 x 1000 40 x 40 4 3000 x 1000 40 x 40 4 3000 x 2000 Schweißgitter Treillis soudés / Welded mesh Maschenweite in mm Drahtstärke Stückgröße 50 x 50 4 3000 x 2000 50 x 50 5 3000 x 2000 50 x 50 6 3000 x 1500 75 x 75 5 2500 x 1250 100 x 100 4 3000 x 1500 100 x 100 5 3000 x 2000 100 x 100 6 2000 x 1000 100 x 50 5 3000 x 2000 200 x 50 6 3000 x 2000 Lieferzeiten auf Anfrage Lieferzeiten auf Anfrage
Walzstahl 173 mm 533 x 765 x 0,20 533 x 765 x 0,37 533 x 765 x 0,32 533 x 765 x 0,42 530 xx 760 x 0,52 530 x 760 x 0,58 Weißbleche Fer blanc / Tinplate mm 530 x 760 x 0,70 530 x 760 x 0,75 530 x 760 x 0,80 533 x 760 x 1,0 Lieferzeiten auf Anfrage Gitterrost-Lagermatten Typ SP-Schweißpressroste mit gedrillten Querstäben, Längsseite glatt eingefasst, Tragstabenden ohne Randeinfassung. Maschenweite: 30 x 30 mm, Größe 6100 x 1000 mm Tragstab: 30 x 2, 30 x 3, 40 x 2, 40 x 3 (mm) Ausführung: Eisenroh oder feuerverzinkt Press-Ultra-Matten Rundum ohne Einfassung, Trag- und Füllstäbe verschweißt Maschenweite: 30 x 30 mm Tragstab: 30 x 2, 30 x 3 (mm) Ausführung: Eisenroh Pressrost-Matten Rundum ohne Einfassung. Maschenweite: 30 x 10 mm Tragstab: 30 x 2, 30 x 3 (mm) Ausführung: Eisenroh Press-Edelstahl-Matten Rundum ohne Einfassung, ungebeizt. Maschenweite: 30 x 30 mm Tragstab: 30 x 2, 30 x 3 (mm)
Walzstahl 174 Press-Gleitschutz-Matten Trag- und Füllstäbe ausgeklinkt, rundum ohne Einfassung. Maschenweite: 30 x 30 mm Tragstab: 30 x 2, 30 x 3 (mm) Ausführung: Eisenroh Press- und Schweißpress-Industrieroste Rundum ohne Einfassung, Trag- und Füllstäbe verschweißt Maschenweite/Tragstab: 30 x 30 / 30 x 2, 30 x 30 / 30 x 3, 30 x 10 / 30 x 2 (mm) Ausführung: Feuerverzinkt Press- und Gleitschutzroste mit ausgeklinkten Trag- und Füllstäben, rutschhemmend Maschenweite/Tragstab: 30 x 30 / 30 x 2, 30 x 30 / 30 x 3 (mm) Ausführung: Feuerverzinkt Press- und Schweißpress-Industriestufen mit Laschen und Sicherheitsantrittskante Maschenweite: 30 x 30 mm Tragstab: 30 x 2, 30 x 3, 40 x 3 (mm) Ausführung: Feuerverzinkt Pressrost-Stufen mit Laschen und Sicherheitsantrittskante Maschenweite: 30 x 10 mm Tragstab: 30 x 2, 30 x 3, 40 x 3 (mm) Ausführung: Feuerverzinkt Pressrost-Gleitschutz-Stufen mit ausgeklinkten Trag- u. Füllstäben, mit Laschen und Sicherheitsantrittskante, rutschhemmend Maschenweite: 30 x 30 mm Tragstab: 30 x 2, 30 x 3, 40 x 3 (mm) Sicherheitsantrittskante für Treppenstufen 6000 mm, eisenroh oder feuerverzinkt Sicherungssysteme feuerverzinkt: Halteklammern, Doppelklammern, Sicherungskette mit Dübel und Schraube Sonderanfertigungen sind auf Anfrage möglich!
